LE910Cx AT Commands Reference Guide
80502ST10950A Rev. 14 Page 1130 of 1904 2022-03-04
Not Subject to NDA
3.15.15. AT#ADC - Read Analog/Digital Converter Input
This command returns the current voltage value of the specified ADC inputs, expressed
in mV.
[1] Hardware User's Guide of the used module
SIM Presence
Setting saved
Can be aborted
MAX timeout
SELINT
Not required
No
No
-
2
AT#ADC=[<adc>,<mode>[,<dir>]]
Execution command reads selected <adc> pin voltage, converts it by
baseband internal ADC and prints outs the result as shown in Additional
info section.
Parameters:
Name
Type
Default
Description
<adc>
integer
1
index of input pin
Value:
1÷n
:
input pin index. For the number of available ADCs
see document [1]
<mode>
integer
2
required action
Value:
2
:
query ADC value
<dir>
integer
0
direction. Its interpretation is currently not
implemented.
