LE910Cx AT Commands Reference Guide
80502ST10950A Rev. 14 Page 939 of 1904 2022-03-04
Not Subject to NDA
3.11.2. AT#STGI - SIM Toolkit Get Information
This command interfaces to the SIM/USIM Application Toolkit to get information on the
ongoing proactive command.
3GPP TS 31.111
Telit SIM/USIM Application Toolkit Application Note
SIM Presence
Setting saved
Can be aborted
MAX timeout
SELINT
Not required
No
No
-
2
AT#STGI=[<cmdType>]
Set command gets parameters of the ongoing proactive command. The
command can be used after the reception of the #STN: <cmdType> URC. If
no proactive command is ongoing, it returns an ERROR message.
Parameter:
Name
Type
Default
Description
<cmdType>
integer
N/A
proactive command code. For each
proactive command listed below, the
response format is described in the
Additional info sections.
Values:
1
:
REFRESH
5
:
SET UP EVENT LIST
16
:
SET UP CALL
17
:
SEND SS
18
:
SEND USSD
19
:
SEND SHORT MESSAGE
