Telit Wireless Solutions LE910C series At Commands Reference Guide

LE910Cx AT Commands Reference Guide
80502ST10950A Rev. 14 Page 1187 of 1904 2022-03-04
Not Subject to NDA
0x08000000
:
GSM BAND 850(B5)
0x10000000
:
GSM BAND 900(B8)
0x20000000
:
GSM BAND 1800(B3)
0x40000000
:
GSM BAND1900(B2)
<ant1_cfg>
integer
0
This parameter can be set when
<enable> parameter is 1.
Values:
0
:
GPIO is Low (default)
1
:
GPIO is High
<ant2_cfg>
integer
0
This parameter can be set when
<enable> parameter is 1.
Values:
0
:
GPIO is Low (default)
1
:
GPIO is High
Additional info:
Signal name
Pin
Description
ant1_cfg
ALT16
Antenna Control 0
ant2_cfg
ALT17
Antenna Control 1
• Tunable antenna pin function of GPIOs correspond to ALT16,17
function of the GPIOs, so it should also set which GPIO will used as
ALT16,17 function through AT#GPIO command. Access those GPIOs
through AT#GPIO command while Tunable antenna function is
enabled is not recommended.
• First, GPIOs what you want to use should set through #GPIO
command before #STUNEANT command setting.
In stuneant "enable" state, tunable antenna gpio cannot be set via
GPIO command.
