#1 Gpio used and supported band is lte:2,4,5,12,13,14,66,71 wcdma:2,4,5, so
All mask value is D6071A for LE910Cx-NF.
AT#GPIO=2,0,17
AT#STUNEANT=1,2,1 ->GPIO2 high set for LTE BAND2
AT#GTUNEANT?
#GTUNEANT: 2,1
#GTUNEANT: D60718,0 ->GPIO2 low set except LTE BAND2
(LTE 4,5,12,13,14,66,71 / WCDMA:2,4,5)
#2 Gpio used and supported band is lte:2,4,5,12,13,14,66,71 wcdma:2,4,5, so
All mask value is D6071A for LE910Cx-NF.
AT#GPIO=2,0,17
AT#GPIO=3,0,18
AT#STUNEANT=1,2,1,1 -> gpio set for LTE BAND2
AT#STUNEANT=1,8,1,0 -> gpio set for LTE BAND4
AT#STUNEANT=1,10,0,1 -> gpio set for LTE BAND5
AT#STUNEANT=1,D60700,0,0 -> (LTE 12,13,14,66,71 / WCDMA 2,4,5)
AT#GTUNEANT?
#GTUNEANT: 2,1,1
#GTUNEANT: 8,1,0
#GTUNEANT: 10,0,1
#GTUNEANT: D60700,0,0
