LE910Cx AT Commands Reference Guide

80502ST10950A Rev. 14 Page 561 of 1904 2022-03-04

Not Subject to NDA

0x02000

EUTRAN BAND14

0x10000

EUTRAN BAND17

0x80000

EUTRAN BAND20

0x1000000

EUTRAN BAND25

0x2000000

EUTRAN BAND26

0x8000000

EUTRAN BAND28

0x00200000000

EUTRAN BAND34

0x02000000000

EUTRAN BAND38

0x04000000000

EUTRAN BAND39

0x08000000000

EUTRAN BAND40

0x10000000000

EUTRAN BAND41

0x8000000000000

EUTRAN BAND66

0x0800000000000000

EUTRAN BAND71

<TDSCDMA_band>

hex

N/A

indicates the LTE supported

bands expressed as the sum of

Band number (1+2+8 ...)

calculated as shown in the table

(mask of 32 bits):

Values:

0x00000

No bands allowed

0x00001

TDS BAND34 A

0x00020

TDS BAND39 F

0x00010

TDS BAND40 E

127 - GSM/WCDMA invalid value
