LE910Cx AT Commands Reference Guide
80502ST10950A Rev. 14 Page 1119 of 1904 2022-03-04
Not Subject to NDA
ALT16 (<dir>=17)
valid for all GPIOs as "Antenna Control
0"
ALT17 (<dir>=18)
valid for all GPIOs as "Antenna Control
1"
ALT18 (<dir>=19)
valid for all GPIOs as "Kernel GPIO
Driver"
- ALT6, ALT11, ALT12, ALT13, ALT15, ALT18 can't be set via #GPIO
- SLED & SWREADYEN will work depending on HW version and are
assigned to ALT1 & ALT10 by default.
- To activate SLED by default, #SLED command should be set to
<mode>=2 after setting ALT1 as follows. (See #SLED, #SLEDSAV
command)
AT#GPIO=1,0,2
OK
AT#SLED=2
OK
AT#SLEDSAV
OK
- ALT6 is available for all GPIOs and this value is only possible to set
by #FASTSHDN.
- ALT15 is available for all GPIOs and this value is only possible to
set by #DGEN.
- LE910C1-EUX/SAX/SVX and LE910Cx-WWX don't support "ALT18".
- While using the pins in the alternate function, the GPIO read/write
access to that pin is not accessible and shall be avoided.
- While GPIO<pin> in used by ALT function, it cannot be set as GPIO
output or any other ALT function before the original ALT released
or change it to GPIO input (default state).
