LE910Cx AT Commands Reference Guide
80502ST10950A Rev. 14 Page 1118 of 1904 2022-03-04
Not Subject to NDA
Name
Type
Default
Description
<dir>
integer
-
Current direction setting of the
GPIO<pin>
<stat>
integer
-
- logic value read from pin GPIO<pin>
in the case the pin <dir> is set to input;
- logic value present in output of the
pin GPIO<pin> in the case the pin <dir>
is currently set to output;
- No meaning value for the pin
GPIO<pin> in the case the pin <dir> is
set to alternate function or Tristate pull
down.
<dir> values from 2 to 19 select an alternate function ranging
respectively from ALT1 to ALT18.
ALTx
Function associated to ALTx
ALT1 (<dir>=2)
valid for GPIO1 as "SLED"
ALT2 (<dir>=3)
valid for all GPIOs: alternate function is
"Alarm Pin"
ALT3 (<dir>=4)
valid for all GPIOs as "TempMon Pin"
ALT4 (<dir>=5)
valid for all GPIOs as "AD_Det Pin"
ALT5 (<dir>=6)
valid for all GPIOs as "AD_Rep Pin"
ALT6 (<dir>=7)
valid for all GPIOs as "FASTSHDN"
ALT7 (<dir>=8)
valid for GPIO4 as "WKIO"
ALT8 (<dir>=9)
valid for ALL "FRATTRIGGER"
ALT9 (<dir>=10)
valid for ALL "HSGC"
ALT10 (<dir>=11)
valid for GPIO8 as "SWREADYEN"
ALT11 (<dir>=12)
valid for ALL GPIOs as "I2C commands"
ALT12 (<dir>=13)
valid for GPIO8 as "W_DISABLE of
PSMWDISACFG"
ALT13 (<dir>=14)
valid for GPIO10 as "VBUS control of
PSMWDISACFG"
ALT14 (<dir>=15)
reserved
ALT15 (<dir>=16)
valid for all GPIOs as "Dying GASP"
