AT#GPIO=2,0,17 -> Setting the ALT16 for GPIO2.
AT#STUNEANT=1 -> All supported band set GPIO2 high.
AT#STUNEANT?
#STUNEANT: 1
AT#GTUNEANT?
#GTUNEANT: 1,D6071A
AT#GPIO=2,0,0 -> Clear the Alternate GPIO setting.
AT#STUNEANT=0 -> Disable the STUNEANT setting.
AT#STUNEANT?
#STUNEANT: 0
AT#GTUNEANT?
ERROR
1. Gpio used and supported band is LTE: 2,4,5,12,13,14,66,71
WCDMA: 2,4,5, so All mask value is D6071A for LE910Cx-NF.
AT#GPIO=2,0,17 -> Setting the ALT16 for GPIO2.
AT#STUNEANT=1,2,1 -> LTE BAND2 set GPIO2 high.
#GTUNEANT:2,1
#GTUNEANT: D60718,0 -> All bands except LTE BAND2 set GPIO2
low.
(LTE 4,5,12,13,14,66,71 / WCDMA:2,4,5)
Case of change the other gpio pin.
AT#STUNEANT=0
AT#GPIO=3,0,18-> Setting the ALT17 for GPIO3.
AT#STUNEANT=1,2,1->LTE BAND2 set the GPIO3 high.
AT#GTUNEANT?
#GTUNEANT: 2,1
