#GTUNEANT: D60718,0 ->All bands except LTE BAND2 set the
GPIO3 low.
(LTE 4,5,12,13,14,66,71 / WCDMA:2,4,5)
2. Gpio used and supported band is lte:2,4,5,12,13,14,66,71
wcdma:2,4,5, so All mask value is D6071A for LE910Cx-NF
AT#GPIO=2,0,17->Setting the ALT16 for GPIO2.
AT#GPIO=3,0,18->Setting the ALT17 for GPIO3.
AT#STUNEANT=1,2,1,1 -> LTE BAND2 set gpios.
AT#STUNEANT=1,8,1,0 -> LTE BAND4 set gpios.
AT#STUNEANT=1,10,0,1 -> LTE BAND5 set gpios.
AT#STUNEANT=1,D60700,0,0 -> (LTE 12,13,14,66,71 / WCDMA 2,4,5)
#GTUNEANT: 2,1,1
#GTUNEANT: 8,1,0
#GTUNEANT: 10,0,1
#GTUNEANT: D60700,0,0
