Acquisition and waveform setup

R&S

RTO6

162User Manual 1801.6687.02 ─ 05

Measurement

Shows the measured common mode voltage.

Remote command:

PROBe<m>:

SETup:TERM:

MEASure? on page 1357

5.6.6 Setup for predefined probes

Probes that cannot be detected, but their characteristics are known to the R&S RTO6

are called "Predefined probes".

The following shared probe settings are available:

●

"Type, Name, Bandwidth" on page 146

●

"Detect AutoZero, Use AutoZero" on page 147

The probe attenuation of the selected probe is also shown in the "Probes" tab:

●

"Probe unit, Auto attenuation" on page 148

Figure 5-13: Probe setup for transmission line probe R&S

RT-ZZ80

Probes
