R&S RTO6 User Manual

Remote control commands
R&S
®
RTO6
2014User Manual 1801.6687.02 ─ 05
SEARch:TRIGger:SWIRe:TYPE <SearchName>,<T
ype>
SEARch:TRIGger:SWIRe:TYPE?
<SearchName>
Sets the search type for the SpaceWire analysis.
Parameters:
<Type> CTRL | DATA | NULL | TIME | ERRor
*RST: CTRL
Parameters for setting and query:
<SearchName>
24.17.15.5 Search results
In all SEARch:RESult:
DPHY:FRAMe<m> commands, the suffix <m> selects the frame
number in the list of search results.
SEARch:RESult:SWIRe:FCOunt?..................................................................................2014
SEARch:RESult:SWIRe:FRAMe<m>:DATA?...................................................................2014
SEARch:RESult:SWIRe:FRAMe<m>:STARt?..................................................................2015
SEARch:RESult:SWIRe:FRAMe<m>:STATe?..................................................................2015
SEARch:RESult:SWIRe:FRAMe<m>:STOP?..................................................................2015
SEARch:RESult:SWIRe:FRAMe<m>:TYPE?.................................................................. 2016
SEARch:RESult:SWIRe:FCOunt? <SearchName>
Returns the number of frames within the search result for the selected serial bus.
Query parameters:
<SearchName>
Return values:
<FrameCount> Range: 0 to 100000
Increment: 1
*RST: 0
Usage: Query only
SEARch:RESult:SWIRe:FRAMe<m>:DATA? <SearchName>
Returns the data value for the selected frame within the search result.
Suffix:
<m>
.
*
Query parameters:
<SearchName>
Return values:
<Data>
Usage: Query only
Protocols
