R&S RTO6 User Manual

Remote control commands
R&S
®
RTO6
2013User Manual 1801.6687.02 ─ 05
SEARch:TRIGger:SWIRe:TIME:CONDition <SearchName>,<T
imeOperator>
SEARch:TRIGger:SWIRe:TIME:CONDition? <SearchName>
Set the condition for the data value of the time code. Y
ou can define an exact value or
a value range.
Parameters:
<TimeOperator> EQUal | NEQual | LTHan | LETHan | GTHan | GETHan |
INRange | OORange
EQUal | NEQual | LTHan | LETHan | GTHan | GETHan
Equal, Not equal, Less than, Less or equal than, Greater Than,
Greater or equal than. These conditions require one data pattern
to be set with the corresponding SEARch:
TRIGger:SWIRe:
TIME:MIN command.
INRange | OORange
In range/Out of range: set the minimum and maximum value of
the range with SEARch:TRIGger:SWIRe:TIME:MIN and
SEARch:TRIGger:SWIRe:TIME:MAX.
*RST: EQUal
Parameters for setting and query:
<SearchName>
SEARch:TRIGger:SWIRe:TIME:MAX <SearchName>,<TimePatternMax>
SEARch:TRIGger:SWIRe:TIME:MAX?
<SearchName>
Sets the the end value of a data type range for the time code if SEARch:TRIGger:
SWIRe:TIME:CONDition is set to INRange or OORange.
Parameters:
<TimePatternMax>
Parameters for setting and query:
<SearchName>
SEARch:TRIGger:SWIRe:TIME:MIN <SearchName>,<TimePatternMin>
SEARch:TRIGger:SWIRe:TIME:MIN?
<SearchName>
Specifies a data bit pattern for the time code, or sets the the start value of a pattern
range.
Parameters:
<TimePatternMin>
Parameters for setting and query:
<SearchName>
Protocols
