R&S RTO6 User Manual

Remote control commands
R&S
®
RTO6
2503User Manual 1801.6687.02 ─ 05
ADVJitter<m>:RESult:PVERtical <State>
If enabled, adds vertical periodic components to the data-dependent synthetic eye.
Suffix:
<m>
.
1..2
Parameters:
<State> ON | OFF
*RST: OFF
ADVJitter<m>:RESult:SYNTheticeye <State>
Selects if you want to display synthetic eye results only for the deterministic jitter (DJ)
components or the data-dependent jitter (DDJ) components.
Suffix:
<m>
.
1..2
Parameters:
<State> ON | OFF
*RST: OFF
ADVJitter<m>:RESult:TYPSynteye <SyntheticEyeTyp>
Selects if you want to display synthetic eye results only for the deterministic jitter (DDP)
components or the data-dependent jitter (DD) components.
Suffix:
<m>
.
1..2
Parameters:
<SyntheticEyeT
yp> DD | DDPH | DDPV | DDP
*RST: DDP
Diagram
ADVJitter<m>:RESult:VER
Tical:HBINs...........................................................................2504
ADVJitter<m>:RESult:VERTical:CONTinuous................................................................. 2504
ADVJitter<m>:RESult:VERTical:BMTYpe........................................................................2504
ADVJitter<m>:RESult:VERTical:BHContinuous............................................................... 2504
ADVJitter<m>:RESult:VERTical:JSContinuous................................................................2505
ADVJitter<m>:RESult:VERTical:NHContinuous...............................................................2505
ADVJitter<m>:RESult:VERTical:NSContinuous............................................................... 2505
ADVJitter<m>:RESult:COMPonents<n>:SCALe..............................................................2505
ADVJitter<m>:RESult:COMPonents<n>:OFFSet.............................................................2506
ADVJitter<m>:DCOMposition:SPJTable..........................................................................2506
ADVJitter<m>:DCOMposition:SPJLabels........................................................................2507
ADVJitter<m>:DCOMposition:SPNLabels.......................................................................2507
ADVJitter<m>:DCOMposition:JINTerleaved.................................................................... 2507
Jitter analysis and clock data recovery

R&S RTO6 Specifications

General

Bandwidth	Up to 6 GHz
Sample Rate	Up to 20 Gsample/s
Memory Depth	Up to 2 Gsample
Channels	Up to 4
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	Up to 16 bit
Trigger Modes	Edge, Pulse
Interface	LAN, USB, GPIB
Input Impedance	50 Ω, 1 MΩ
