R&S RTO6 User Manual

Remote control commands
R&S
®
RTO6
2010User Manual 1801.6687.02 ─ 05
Return values:
<Stop> Range: -100E+24 to 100E+24
Increment: 100E-12
*RST: 0
Default unit: s
Usage: Query only
BUS<m>:SWIRe:RESults:FRAMe<n>:FLD<o>:TYPE?
Returns the type of the field with the selected field number within the frame with the
selected frame number.
Suffix:
<m>
.
1..4
<n> *
Selects the frame number.
<o> *
Selects the field number.
Return values:
<FrameByteV
alue>
Usage: Query only
BUS<m>:SWIRe:RESults:FRAMe<n>:FLD<o>:VAL?
Returns the value of the field with the selected field number within the frame with the
selected frame number.
Suffix:
<m>
.
1..4
<n> *
Selects the frame number.
<o> *
Selects the field number.
Return values:
<FrameByteV
alue> Range: 0 to 65535
Increment: 1
*RST: 0
Usage: Query only
24.17.15.4 Search settings
SEARch:TRIGger:
SWIRe:CTYPe.................................................................................. 2011
SEARch:TRIGger:SWIRe:DATA:CONDition.................................................................... 2011
SEARch:TRIGger:SWIRe:DATA:MAX.............................................................................2012
SEARch:TRIGger:SWIRe:DATA:MIN..............................................................................2012
Protocols
