Remote control commands

R&S

RTO6

2009User Manual 1801.6687.02 ─ 05

Suffix:

<m>

1..4

<n> *

Selects the frame number.

<o> *

Selects the field number.

Return values:

<Start> Range:

-100E+24 to 100E+24

Increment: 100E-12

*RST: 0

Default unit: s

Usage: Query only

BUS<m>:SWIRe:RESults:FRAMe<n>:FLD<o>:STATus?

Returns the status of the field with the selected field number within the frame with the

selected frame number

Suffix:

<m>

1..4

<n> *

Selects the frame number.

<o> *

Selects the field number.

Return values:

<State> OK |

PAR | ESC | AMB | INComplete

PAR: parity error

ESC: escape

AMB: ambiguous

*RST: OK

Usage: Query only

BUS<m>:SWIRe:RESults:FRAMe<n>:FLD<o>:STOP?

Returns the stop time of the field with the selected field number within the frame with

the selected frame number.

Suffix:

<m>

1..4

<n> *

Selects the frame number

<o> *

Selects the field number.
