Remote control commands

R&S

RTO6

2008User Manual 1801.6687.02 ─ 05

Suffix:

<m>

1..4

Selects the serial bus.

<n> *

Selects the frame.

Return values:

<Type> DATA | FCT | EOP | EEP | ESC | NULL | TCOD

DAT

Data frame

FCT

Flow control token

EOP

End of packet

EEP

Error end of packet

ESC

Escape

NULL

Null symbol

TCOD

Time code

*RST: DATA

Usage: Query only

BUS<m>:SWIRe:RESults:FRAMe<n>:FLD<o>:FVAL?

Returns the formatted value of the field with the selected field number within the frame

with the selected frame number

Suffix:

<m>

1..4

<n> *

Selects the frame number.

<o> *

Selects the field number.

Return values:

<FrameByteV

alue>

Usage: Query only

BUS<m>:SWIRe:RESults:FRAMe<n>:FLD<o>:STARt?

Returns the start time of the field with the selected field number within the frame with

the selected frame number.
