Remote control commands

R&S

RTO6

2007User Manual 1801.6687.02 ─ 05

BUS<m>:SWIRe:RESults:FRAMe<n>:STATe?

Returns the overall state of the frame.

Suffix:

<m>

1..4

Selects the serial bus.

<n> *

Selects the serial bus.

Return values:

<State> OK | PAR | ESC | AMB | INComplete

The frame is valid.

PARity

Parity error

ESC

Escape error

AMB

Ambiguous

INComplete

The frame is incomplete

*RST: OK

Usage: Query only

BUS<m>:SWIRe:RESults:FRAMe<n>:STOP?

Returns the end time of the specified frame.

Suffix:

<m>

1..4

Selects the serial bus.

<n> *

Selects the frame.

Return values:

<Stop> Range: -100E+24 to 100E+24

Increment: 100E-12

*RST: 0

Default unit: s

Usage: Query only

BUS<m>:SWIRe:RESults:FRAMe<n>:TYPE?

Returns the type of frame.
