Status Indicator RAPs
Replace the Tray 1 No Paper Sensor (PL 2.5).
Go to Flag 6 on BSD 7.5 and check the wires for an open or short circuit. If the wires are
OK
, replace the IOT Drive PWB (PL 9.2).
Check/replace the following parts in the order listed until t
he problem is resolved. Replace any
parts that are worn, broken, binding, or missing.
• Tray 1 Paper Feed Assembly (PL 2.4)
• Tray 1 Assembly (PL 2.
1)
• Wiring Harness
7-282 Tray 2 Lift Motor Failure RAP
The Tray 2 Stack Height Sensor failed to change state within the specified time after Tray 2 Lift/
Feed Motor was energized.
Initial Actions
• Refer to BSD 7.6 and BSD 7.10 for the following procedure.
• Ensure there is paper loaded in the Tray 2.
• Ensure connector P/J8
03 on the Tray PWB is properly seated (PL 9.3).
• Check for crimped or broken wires t
o connectors on the IOT Drive PWB (PL 9.2).
• Pull out Paper Tray 2.
• Open the Lower Left Door (PL 2.
8).
• Remove the Screw and open the Tray 2 Feed Assembly (PL 2.4).
Procedure
Cheat the L/H Cover INTLK Switch. Remove the Tray 2 Feed Assembly without disconnecting
P/J792. Enter dC330 008-222 Tray 2 Level Sensor. Press Start. Manually actuate the Tray 2
Stack Height Sensor. The display changed from H to L.
YN
+0 VDC is measured at P
/J415A-15 o
n the IOT Drive PWB and GND.
YN
+5 VDC is measured at P
/J130-
2 on the Tray 2 Stack Height Sensor.
YN
Go to F
lag 5 and Fla
g 6 on BSD 7.6 and check the harness and connectors. If
the harness and connectors are OK, replace the IOT Drive PWB.
+5 VDC is measured between P/J130-1 and
P/J130-3 on the Tray 2 Stack
Height Sensor.
YN
+5 VDC is measured between P/
J21-1 an
d P/J21-5 on the IOT LVPS.
YN
Go to the +
5 VD
C Power (IOT LVPS) RAP.
+5 VDC is measured between P/J803
-A11 on the Tray PWB and P/J21-5
on the IOT LVPS.
YN
Replace the IOT Drive PWB (PL
9.
2).
Go to Flag 5 on BS
D 7.6 and check wires for an open circuit. If the wires are
OK, replace the Tray PWB (PL 9.3).
Replace the Tray 2 Stack Height Sensor (PL 2.5).
Go to Flag 6 on BS
D 7.6 and check the wire for an open or a short circuit. If the wire is
OK, replace the IOT Drive PWB (PL 9.2).
Push the Tray in. Enter dC330 008-0
12 Tray 2 Feed/Lift Motor (Lift), 008-013 Tray 2 Feed/
Lift Motor (Feed) Tray 2 Feed/Lift Motor. Press Start and Stop several times.
A B C
