10-115 Exit Path Sensor On Jam RAP, 10-117 Exit
Reissue
Status Indicator RAPs
YN
Press Stop. + 5 VD
C is measured between P/J417B-11 and GND on the IOT Drive
PWB.
YN
+5 VDC is measured between P/
J42-
8 and P/J42-7 on the Distribution PWB.
YN
Replace the Distribution PWB (PL
9.
3).
Go to Flag 1 and
Flag 4 on BSD 10.4 and check the harnesses for an open circuit. If
the harnesses are good, replace the Fuser Motor (PL 1.6)
Press Start. T
he voltage at P/J417B-11 momentarily goes to less than +1.0 VDC.
YN
Replace the IOT Drive PWB (PL 9.
2).
+24 V
DC is measured between P/J42-
6 on the Distribution PWB and GND.
YN
Replace the Distribution PWB (PL
9.
3).
Go to Flag 2 and Fla
g 3 on BSD 10.4 and check the harnesses for an open circuit. If the
harnesses are good, replace the Fuser Motor (PL 1.6). If the problem continues, replace
the IOT Drive PWB (PL 9.2).
Check for obvious damage, missing and/or broken Drive Mot
or
gear assemblies and drive
belts that would cause the paper to be slow to actuate the Exit Path Sensor.
10-117 Exit Path Sensor On Jam RAP
The Exit Path Sensor detected paper when closing the Inverter Cover or when the power was
switched on.
Initial Actions
Refer to BSD 10.7 and 10.12 for the following procedure.
Check for the following:
• Open the Inverter Door (PL 2.23
) and clean the Exit Path Sensor. Also, ensure that the
sensor actuator is moving freely.
• Ensure that connectors P/J412B and P/J164 ar
e seated correctly on the IOT Drive PWB
and the Exit Path Sensor, and there are no obvious crimped or broken wires.
• Ensure the Inverter is closed. Switch the power Off then On.
Procedure
Enter dC330 010-115 Exit Path Sensor. Press Start. The display indicates L.
YN
Go to F
lag 5 and Fl
ag 6 on BSD 10.7 and check the harness for a open circuit. If the har-
ness is good, replace the Exit
Path Sensor (PL 2.25).
If the fault code is present and can not be cleared, replace the IOT Drive PWB (PL 9.2)
. If the
fault code is not present and is occurring intermittently, go to Flag 5 and Flag 6 on BSD 10.7
and check the harness for an intermittent open circuit. If the harness is OK, replace the Exit
Path Sensor (PL 2.25). If the problem continues, replace the IOT Drive PWB (PL 9.2).
