Xerox DocuColor 12/DCCS50

1/05
2-73
DocuColor 12/DCCS50
Status Indicator RAPs
Reissue
YN
+24 VDC is measured between P/J23-
3 and GND on the IOT LVPS.
YN
Go to the +
24
VDC Power (IOT LVPS) RAP.
Go to Flag 1 on BSD 1.2 and check for an open wiring. If the wiring is OK, replace the
Tr
ay PWB (PL 9.3).
Replace the Tray PWB (PL 9.3).
7-500 Tray out of position during Job RAP
The machine detected that the Tray is out of position during the Job.
Initial Actions
• Refer to BSD 7.1 through BSD 7.3 for the following procedure.
• Ensure the Tray attributes selected match the paper loaded in the Tray.
• Ensure that the End Guides are properly adjusted t
o the paper in the Tray.
• Ensure Connector PJ802 on the Tray PWB is seated pr
operly for Trays 2,3,4.
• Ensure that there are no obvious cri
mped or broken wires.
Procedure
Tray 2 was in use when the fault occurred.
YN
Tray 3 was in use when the fault occurred.
YN
Enter d
C330 and Active Stack 008-250 Tray 4 size switch 1, 008-251 T
ray 4 size
switch 2, 008-252 Tray 4 size switch 3, 008-253 Tray 4 size switch 4 for the Tray 4
Size Sensor and press Start. Open Tray 4. Check the state of the four Tray Sensors.
The four Tray Sensor States displayed corresponds with Table 3.
YN
Check for +XVDC (Refer to Table 3 for the DC Voltages) +XVDC is measured
at T
P-8 o
n the Tray PWB.
YN
Check for +XVDC (Refer to Table 3 for the DC Voltages) +XVDC is mea-
sured at P
/J415B-
14 on the IOT PWB.
YN
Go to the +
5 VD
C Power (IOT LVPS) RAP.
Go to Flag 1 and Fl
ag 2 on BSD 7.3 and check the harness and connec-
tors. If the harness and connectors are OK,
replace the Tray 4 Size Sen-
sor (PL 2.1).
Replace the T
ray PWB (PL 9.3).
Check/Replace the following parts in the order listed u
ntil the problem is resolved.
Replace any parts that are worn, broken, binding, or slipping.
• Tray 4 Assembly (PL 2.
4).
• Tray 4 Size Sensor (PL 2.1).
Enter dC330 and Active Stack 008-245 Tray 3 size switch 1, 0
08-246 Tray 3 size switch
2, 008-247 Tray 3 size switch 3, 008-248 Tray 3 size switch 4 for the Tray 3 Size Sensor
and press Start. Open Tray 3. Check the state of the four Tray Sensors. The four Tray
S
ensor
States displayed corresponds with Table 2.
YN
Check for +XVDC (Refer to Table 2 for the DC Voltages) +XVDC is measured at
T
P-7 o
n the Tray PWB.
A B
