Xerox DocuColor 12/DCCS50 User Manual

1/05
2-97
DocuColor 12/DCCS50
8-154 Pre Registration Sensor On RAP, 8-157 Reg-
Status Indicator RAPs
Reissue
8-154 Pre Registration Sensor On RAP
The Pre Registration Sensor detected paper when closing the Front Cover or when power was
switched on.
Initial Actions
• Refer to BSD 8.8 and BSD 8.10 for the following procedure.
• Check for any obstructions in the paper path.
Procedure
Enter dC330 008-153 Pre Registration Sensor. Press Start. The display indicates H.
YN
Go to Fl
ag 1 on BS
D 8.8 and check the harness for a short circuit. If the harness is OK,
replace the Pre Registration Sensor (PL 2.16).
If the fault code is present and can not be cleared, replace the IOT Drive PWB (PL 9.
2). If the
fault code is not present and is occurring intermittently, go to Flag 1 on BSD 8.8 and check the
harness for an intermittent short circuit. If the harness is OK, replace the Pre Registration Sen-
sor (PL
2.16). I
f the problem continues, replace the IOT Drive PWB (PL 9.2).
8-157 Registration Sensor On Jam RAP
The Registration Sensor detected paper when closing the Front Cover or when power was
switched on.
Initial Actions
• Refer to BSD 8.8 and BSD 8.10 for the following procedure.
• Check for any obstructions in the paper path.
Procedure
Enter dC330 008-155 Registration Sensor. Press Start. The display indicates H.
YN
Go to F
lag 5 on BSD 8.8 and check the harness for a short circuit. If the harness is OK,
replace t
he Registration Sensor (PL 2.15).
If the fault code is present and can not be cleared, replace the IOT Drive PWB (PL 9.2)
. If the
fault code is not present and is occurring intermittently, go to Flag 5 on BSD 8.8 and check the
harness for an intermittent short circuit. If the harness is OK, replace the Registration Sensor
(PL 2.15). If the problem continues, replace the IOT Drive PWB (PL 9.2).
