1/05

2-20

DocuColor 12/DCCS50

3-340 IOT RAM Fail RAP, 3-356 IOT NVM Failure RAP

Reissue

Status Indicator RAPs

3-340 IOT RAM Fail RAP

This Fault Code indicates that it was detected at power on that the IOT PWB RAM Test failed.

Initial Actions

• Refer to BSD 3.12 Monitoring in this procedure:

• Check the NVM settings related to the IOT-SYS logic.

Procedure

PO/PO the machine. Fault Code 3-340 is still declared.

If intermittent behavior is suspected, perform the following:

• Inspect the IOT NVM PWB and the IOT CPU PWB connections.

• Reseat connectors between the IOT NVM PWB and IOT CPU PWB

Replace the IOT NVM PWB (PL 9.2).

3-356 IOT NVM Failure RAP

This Fault Code indicates that the IOT PWB NVM test failed and was detected at Power On.

Initial Actions

• Refer to BSD 3.12 Monitoring in this procedure:

Procedure

PO/PO the machine. Fault Code 3-356 is still declared.

If intermittent performance is suspected, inspect the IOT CPU PWB, and the IOT NVM

B f

or loose connections or any obvious electrical/mechanical cause for malfunction.

Replace the IOT NVM PWB (PL 9.2).
