1/05

2-45

DocuColor 12/DCCS50

5-195 No Mix - Size Mismatch Jam RAP, 5-196

Status Indicator RAPs

Reissue

5-195 No Mix - Size Mismatch Jam RAP

The DADF Control PWB detected different sized documents when the mixed sized feature has

not been selected.

Procedure

This is a message Fault and requires operator actions. If this Fault occurs and the originals are

all the same size, check that the Side Guide can be properly adjusted against the stack. If so,

go to the 5-274 Original Size Sensor Fail RAP.

5-196 DADF Document Sensor Static Jam RAP

The DADF Document Sensor detected paper when power was switched on.

Initial Actions

Check for the following:

• Refer to BSD 5.2 for the following procedure.

• Contamination on the DADF Document Sensor.

• Ensure that connectors P/J5

99 and P/J581 are seated correctly on the DADF Control

PWB and DADF Document Sensor and there are no obvious crimped or broken wires.

• Ensure that the DADF Entrance Tray is fr

ee of any paper or debris.

Procedure

Enter dC330 005-102 Document Sensor. Press Start. The display is H.

+5 VDC is measured between P/

J599-5 an

d GND on the DADF Control PWB.

Go to F

lag 4 on BSD 5.2. Check the wire for a short circ

uit to ground. If the wire is

good, replace the DADF Document Sensor (PL 12.5).

Replace the DADF Control PWB (PL 12.3).

The problem appears to be intermittent. Replace t

he DADF Document Sensor (PL 12.5). If the

problem continues, replace the DADF Control PWB (PL 12.3).
