DocuColor 12/DCCS50
11-146 Decurler Exit Sensor On Jam Short RAP, 11-
Finisher/Sorter
Reissue
YN
+5 VDC is measured between P/J
651-3 and P/J651-4 on the Finisher PWB.
YN
+5 VDC is measured between P
/J1028
-3 and P/J1028-4 on the Finisher
PWB.
YN
+5 VDC is measured between P/J
880
-3 and P/J880-2.
YN
Go to the +5VDC F
igure 1
wirenets and check wires for an open or
short circuit.
Go to Flag 17 on BS
D 12.1 and check the harness for an open circuit.
Replace the Finisher PWB (PL 18.4).
Replace the Decurler Exit Sensor (PL 18.6).
Go to Fl
ag 9 on BS
D12.6. Check the wire for an open circuit. If the wires are good,
replace the Decurler Exit Sensor (PL 18.6).
More than +4.5 VDC is measured between P/J658-2 and
GND on the Decurler Exit Sen-
sor.
YN
Replace the Decurler Exit Sensor (PL 18.6).
Check the following parts for wear, glazing, or slipping.
• Mailbox Entrance Roll (PL
18
.10)
• Pinch Rollers (PL 1
8.12)
• SCT Exit Roll (PL 18.10)
•
Drive Belt (PL 18
.10)
• Drive gears (PL 18
.7) (PL 18.8)
11-190 Paper Remains on V-Tra In Sensor RAP
The Control Logic detected that paper remained on the V-Tra In Sensor at power on.
Initial Actions
• Refer to BSD12.7 and BSD12.17 for the following procedure.
• Ensure that no paper is blocking the V-Tra In sensor and t
he sensor actuator moves freely.
• Check for any obstructions in the paper path.
• Ensure that P/J104
0 on the Finisher PWB, P/J1076 double plug, and P/J1017 on the
Mailbox Entrance Sensor are connected before beginning this RAP.
Procedure
Enter dC330 012-142 Mailbox Entrance Sensor. Press Start. The display is L.
YN
Go to F
lag 7 and
Flag 8 on BSD12.7 and check the harness for a short circuit. If the har-
ness is good, replace the Mailbox Entrance
Sensor (PL 18.13). If the problem continues,
replace the Finisher PWB (PL 18.4).
More than +4.3 VDC is measured between P/J1040
-4 and GND on the Finisher PWB.
YN
Replace the Mailbox Entrance Sensor (PL
18.13).
Check
the Mailbox Entrance Sensor for intermittent oper
ation. If the sensor is good, Replace
the Finisher PWB (PL 18.4).
H
