Xerox DocuColor 12/DCCS50 User Manual

1/05
2-209
DocuColor 12/DCCS50
11-914 Bin 4 Full Stack RAP, 11-915 Bin 5 Full Stack
Status Indicator RAPs
Reissue
11-914 Bin 4 Full Stack RAP
The Control Logic detected that Bin 4 is full.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-914 Bi
n 4 Full
Stack RAP to troubleshoot this Fault Code.
Initial Actions
• Refer to BSD11.6 for the following procedure.
• Ensure that Bin 4 is empty
Procedure
Enter dC330 011-284 Bin 4 Full Sensor. Press Start. Manually move the actuator in and out
of the sensor The display Changes from H to L to H as the actuator is moved in and out
of th
e sensor.
YN
Replace the Mail Box Control PWB (PL 13.10).
Check the Bin 4 Full Sensor for intermittent operat
ion. I
f the problem continues, replace the
Mail Box Control PWB (PL 13.10).
11-915 Bin 5 Full Stack RAP
The Control Logic detected that Bin 5 is full.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-915 Bi
n 5 Full
Stack RAP to troubleshoot this Fault Code.
Initial Actions
• Refer to BSD11.6 for the following procedure.
• Ensure that Bin 5 is empty
Procedure
Enter dC330 011-285 Bin 5 Full Sensor. Press Start. Manually move the actuator in and out
of the sensor The display Changes from H to L to H as the actuator is moved in and out
of t
he sensor.
YN
Replace the Mail Box Control PWB (PL 13.
10).
Check t
he Bin 5 Full Sensor for intermittent operation. I
f the problem continues, replace the
Mail Box Control PWB (PL 13.10).
