Xerox DocuColor 12/DCCS50 User Manual

1/05
8d-29
DocuColor 12/DCCS50
11-915 Bin 5 Full Stack RAP, 11-916 Bin 6 Full Stack
Finisher/Sorter
Reissue
11-915 Bin 5 Full Stack RAP
The Control Logic detected that Bin 5 is full.
Initial Actions
• Refer to BSD12.9 for the following procedure.
• Ensure that Bin 5 is empty
Procedure
Enter dC330 012-285 Bin 5 Full Sensor. Press Start. Manually move the actuator in and out of
the sensor The display Changes from H to L to H as the actuator is moved in and out of
the s
ensor.
YN
Press Stop. +5VDC is measured between P
/J1002-
5 and DC COM on the Mailbox
PWB.
YN
+5VDC is measured between P/
J1031-7 and
DC COM on the Finisher PWB.
YN
Replace the Finisher PWB (PL 18.4).
Go to Fl
ag 5 on
BSD12.9 and check the wires for an open circuit.
Replace the Mailbox PWB (PL 1
8.11).
Check the Bin 5 Full Sensor for intermittent operation. I
f the problem continues, replace the
Mailbox PWB (PL 18.11).
11-916 Bin 6 Full Stack RAP
The Control Logic detected that Bin 6 is full.
Initial Actions
• Refer to BSD12.9 for the following procedure.
• Ensure that Bin 6 is empty
Procedure
Enter dC330 012-286 Bin 6 Full Sensor. Press Start. Manually move the actuator in and out of
the sensor The display Changes from H to L to H as the actuator is moved in and out of
the senso
r.
YN
Press Stop. +5VDC is measured between P
/J10
02-6 and DC COM on the Mailbox
PWB.
YN
+5VDC is measured between P
/J1031
-6 and DC COM on the Finisher PWB.
YN
Replace the Finisher PWB (PL 18.
4).
Go
to Flag 6 on BS
D12.9 and check the wires for an open circuit.
Replace the Mailbox PWB (PL 18.11
).
Check the Bin 6 Full Sensor for intermittent operation. I
f the problem continues, replace the
Mailbox PWB (PL 18.11).
