1/05
6-155
DocuColor 12/DCCS50
Product Specifications
General Procedures
Reissue
Copy (Print) Paper
1. Tray (B5~A3, Letter)
a. NO1 Tray: 64~105gsm
b. NO2~4 Tray: 64~128gsm (105~128gsm paper: Select “Thick Paper 1”.)
2. Tray 5: 64~250gsm
Paper Cassette Type
Paper sizes and orientation loadable in each tray are as follows:
NOTE: Tray 5 paper sizes are selected from the Control Panel.
Table 21 Paper Part Numbers
NASG Market ESG Market
For B/W 4024DP (20#) 80 gsm Premier
3
R91720,
3R91721
For Color Color Xpressions
9
3 (24#
bond)
3R5464,
3R5465
Colortech Plus
(
90gsm)
3R94641 (A4),
3R94642 (A3)
Table 22 Paper Size Specifications
Tray 1
NASG spec (8.5x11) LEF
ESG spec A4 LEF
A5 SEF, A4 LEF, Letter (8.5x11) LEF paper load is possible if
paper guide posit
ion is changed
and the size is input in “NVM R/W
(dC131)” or in “Configuration Page (dC371)”.
Table 23 Paper Size Specifications
Tray 2,3 and 4
NASG spec. Common specification among NASG and
E
SG.
A3SEF, B4SEF, A4SEF, A4LEF, B5SEF,
B5LEF, Letter (8.5x11) SEF, Letter (8.5x11)
LEF, Legal (8.5x14) SEF, 11x17 SEF, 8th
Opening SEF, Suryu-kai LEF, Legal (8.5x13)
SEF, 8x10 LEF
ESG spec.
12x18 SEF can be loaded in special Tray 5.
12x18 SEF can be loaded in Trays 2,3 or 4 if modified by the CSE
pe
r AD
J 9.1.19 (Tray 2, 3, and 4 for 12 x 18 Paper).
For the irregular sized paper, tray can be used if paper guide posi-
tion is changed and the size is input using the User Interface.
Table 24 Tray Settings
Tray 1 Refer to: Table 22
Tr
ay 2-4 Adjustable Tray ²
Tray 5 Adjustable Tray ¹
HCF (option) Adjustable Tray ² (8.5x11 or A4 only)
¹ Set Paper Guides at new paper position and select the loaded
p
aper size using t
he User Interface.
² Paper size setting is performed automatically at setting the guide
for t
he regular sized paper.
Table 25 Tray 5 Paper Sizes
Machine can detect the
f
ollo
wing sizes of originals. Tray 5
Paper Size / Orientation
NASG ESG
Postcard SEF 100X148 - -
(Post Card) LEF (101X152) X ALT ²
(Post Card) LEF (101X152) X ALT ²
A6 SEF 105X148 ALT ³ X
A6 LEF 105X148 ALT ³ X
B6 SEF 128X182 X X
B6 LEF 182X128 - -
A5 SEF 148X210 X X
A5 LEF 210X148 X X
5.5X8.5 SEF 140X215.9 X X
5.5X8.5 LEF 215.9X140 X X
B5 SEF 215.9X279.4 X X
B5 LEF 279.4X215.9 X X
A4 SEF 210x297 X X
A4 LEF 297x210 X X
8x10 SEF X -
8x10 SEF X -
8x11 SEF 215.9x279.4 X -
8x11 LEF 279.4x215.9 X X
8.5X13 SEF 215.9X330.2 - X
8.5X14 SEF 215.9X355.6 X X
8.5X14 SEF 215.9X355.6 X -
B4 SEF 257X364 - X
