Xerox DocuColor 12/DCCS50 User Manual

1/05
8d-28
DocuColor 12/DCCS50
11-913 Bin 3 Full Stack RAP, 11-914 Bin 4 Full Stack
Reissue
Finisher/Sorter
11-913 Bin 3 Full Stack RAP
The Control Logic detected that Bin 3 is full.
Initial Actions
• Refer to BSD12.9 for the following procedure.
• Ensure that Bin 3 is empty
Procedure
Enter dC330 012-283 Bin 3 Full Sensor. Press Start. Manually move the actuator in and out of
the sensor The display Changes from H to L to H as the actuator is moved in and out of
the s
ensor.
YN
Press Stop. +5VDC is measured between P
/J1002-
3 and DC COM on the Mailbox
PWB.
YN
+5VDC is measured between P/
J1031-9 and
DC COM on the Finisher PWB.
YN
Replace the Finisher PWB (PL 18.4).
Go to Fl
ag 3 on
BSD12.9 and check the wires for an open circuit.
Replace the Mailbox PWB (PL 1
8.11).
Check the Bin 3 Full Sensor for intermittent operation. I
f the problem continues, replace the
Mailbox PWB (PL 18.11).
11-914 Bin 4 Full Stack RAP
The Control Logic detected that Bin 4 is full.
Initial Actions
• Refer to BSD12.9 for the following procedure.
• Ensure that Bin 4 is empty
Procedure
Enter dC330 012-284 Bin 4 Full Sensor. Press Start. Manually move the actuator in and out of
the sensor The display Changes from H to L to H as the actuator is moved in and out of
the senso
r.
YN
Press Stop. +5VDC is measured between P
/J10
02-4 and DC COM on the Mailbox
PWB.
YN
+5VDC is measured between P
/J1031
-8 and DC COM on the Finisher PWB.
YN
Replace the Finisher PWB (PL 18.
4).
Go
to Flag 4 on BS
D12.9 and check the wires for an open circuit.
Replace the Mailbox PWB (PL 18.11
).
Check the Bin 4 Full Sensor for intermittent operation. I
f the problem continues, replace the
Mailbox PWB (PL 18.11).
