8-150 Tray 4 Takeaway Sensor On Jam RAP, 8-152
Reissue
Status Indicator RAPs
Press the Start button. The voltage at P/J802B-9 goes to approximately 0 VDC.
YN
There is +5 VDC between P
/J801B-
6 on the Tray PWB and GND.
YN
Go to Fl
ag 6 on BS
D 8.4 and check the harness for an open circuit. If the har-
ness is good, replace the IOT Drive PWB
Replace the Tray PWB (PL 9.3).
Replace the Tray 4 Takeaway Feed Clutch (PL 2.7
A).
Check/replace the following components until the problem is resolved. Replace any compo-
nents that are worn, broken, binding, or slipping.
• Pinch Rolls and Springs (PL 2.8)
• Check for burrs on the Baffle (PL 2.
8)
• Gears in the Takeaway Drive Assembly (PL 2.7A)
8-152 Takeaway Sensor On RAP
The Takeaway Sensor detected paper when closing the Front Cover or when power was
switched on.
Initial Actions
• Refer to BSD 8.6 and BSD 8.10 for the following procedure.
• Check for any obstructions in the paper path.
• Open the Lower Left Door (PL 2.
8).
Procedure
Cheat the L/H Cover Interlock Switch. Enter dC330 008-150 Take Away Sensor. Press the
Start button. The display indicates H.
YN
Go to F
lag 1 on BSD 8.6 and check the harness for a short circuit. If the harness is OK,
replace th
e Takeaway Sensor (PL 2.8).
If the fault code is present and can not be cleared, replace the IOT Drive PWB (PL 9.2)
. If the
fault code is not present and is occurring intermittently, go to Flag 1 on BSD 8.6 and check the
harness for an intermittent short circuit. If the harness is OK, replace the Takeaway Sensor (PL
2.8). If the problem continues, replace the IOT Drive PWB (PL 9.2).
