DocuColor 12/DCCS50
dC131 Sorter/Finisher NVM List (780), dC132 Serial
General Procedures
Reissue
dC131 Sorter/Finisher NVM List (780)(790) dC132 Serial Number/Billing Meter Synchronization
Purpose
Checks the Billing Meters and sets the Machine Serial Number when fault 3-397 occurs. This
routine also reads the Billing Meters and can be accessed at any time for this purpose.
Procedure
CAUTION
Failure to comply with the board replacement procedur
e in GP 10 Replacing Billing PWBs ,
could result in catastrophic NVM corruption.
Follow the procedure described in GP
10 Replacing Billing PWBs .
Table 1 Sorter/Finisher NVM List (780, 790)
Chain-
Link Na
me Default Range Description
780-001 Sorter Mail Box switching 0 0-1 0= Sorter, 1= MailBox
780-002 JAM counter (011-145) 0 0-99 number of jams
780-003 JAM counter (011-146) 0 0-99 number of jams
780-004 JAM counter (011-142) 0 0-99 number of jams
780-005 JAM counter (011-144) 0 0-99 number of jams
780-006 JAM counter (011-143) 0 0-99 number of jams
780-007 JAM counter (011-115) 0 0-99 number of jams
780-008 JAM counter (011-116) 0 0-99 number of jams
780-009 JAM counter (011-107) 0 0-99 number of jams
780-010 JAM counter (011-109) 0 0-99 number of jams
780-011 JAM counter (011-108) 0 0-99 number of jams
780-012 Fail counter (011-273) 0 0-99 number of jams
780-013 Fail counter (011-274) 0 0-99 number of jams
780-020 Humidity (%) 0 0-100 Current humidity data
(Det
ected by
the environment
sensor)
780-021 Toner ratio: Zl Side1 (%) 0 0 - 100 Last Copy Side1: Toner ratio
of
fi
rst 1/3
780-022 Toner ratio: Zl Side2 (%) 0 0 - 100 Last Copy Side2: Toner ratio
of fi
rst 1/3
780-023 Toner ratio: Zt Side1 (%) 0 0 - 100 Last Copy Side1: Toner ratio
of last
1/3
780-024 Toner ratio: Zt Side2 (%) 0 0 - 100 Last Copy Side2: Toner ratio
of last
1/3
780-028 Decurler: Forced control 0 0 - 3 0= AUTO
1= Dec1 Only
2= Dec2 Only
3= Release Only
790-032 Stacker Capacity 0 0 - 1 0= 100 sets
1= 60 sets
790 -033 Set Eject 0 0 - 1 0= 50 sheets
1= 25 sheets
