1/05
2-187
DocuColor 12/DCCS50
11-108 OCT Exit Sensor Off Jam RAP, 11-109 OCT
Status Indicator RAPs
Reissue
Check the Drive Belt Tension Roll for proper tension.
Check the Drive Belt for Damage
Check that the gear pulleys are properly fas
tened to the drive rolls
Check the following parts for wear, glazing, or slipping.
Entrance Roll (PL 1
3.9)
Pinch Rollers (PL 1
3.9)
Exit Roll (PL 13.9)
Drive Belt (PL 13
.10)
Check the Drive Belt Tension Roll for proper tension.
Check the OCT Exit Sensor Actuator for binding as it
moves in and out of the sensor. The
actuator is binding.
YN
Check for obvious damage, missing and/or broken Dr
iv
e Motor gear assemblies and drive
belts that would cause the copy to be slow to actuate the OCT Exit Sensor.
Replace the OCT Exit Sensor (PL 1
3.9).
11-109 OCT Exit Sensor On Jam Short RAP
The OCT Exit Sensor did not detect the lead edge of the paper within the specified time after
the Decurler Exit Sensor detected the trail edge of the same paper.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-109
SCT Exit
Sensor On Jam Short RAP to troubleshoot this Fault Code.
NOTE: “Short” indicates that the trail edge of the paper has passed through the Decurler Exit
Sensor.
Initial Actions
Refer to BSD11.2 and BSD 11.4 and BSD 11.8 for the following procedure.
Check for the following:
Obstructions in the Mail Box paper path
Bent or out of position paper chutes/guides in the Mail Box paper path
Ensure that there is sufficient nip force at the Mail Box Transport Roll and the Oct Exit
Roll.
Ensure that connectors P/J
562 on the Mail Box Control PWB and P/J566 on the OCT
Exit Sensor are seated correctly and there are no obvious crimped or broken wires.
Procedure
The lead edge of the paper is at or past the Oct Exit Sensor
YN
The paper entered the Vertical Transport.
YN
Enter d
C330 011-005 Mailbox Drive Motor. Press St
art. The Mail Box Transport
Roll is rotating.
YN
The Mail Box Drive Belt is moving.
YN
The Mail Box Drive Motor is rotating
YN
+24 VDC is measured between P/
J572-1 and
P/J572-2 of the
Mail Box Drive Motor
YN
Go to Fl
ag 1on BS
D11.2. Check the wires for an open circuit. If
the wires are good, replace the Mail Box Control PWB (PL
13.10).
Press St
op. +5 VDC i
s measured between P/J572-3 and GND.
YN
Go to F
lag 3 on BSD 11.2. Check the wire for an open circuit. If
th
e wire is good, replace the Mail Box Control PWB (PL 13.10).
Press Start. Less th
an +1 VDC is measured between P/J572-3
and GND.
YN
Replace the Mail Box Control PWB (PL 13.10)
A B C
A B C D E F
