Xerox DocuColor 12/DCCS50 User Manual

1/05
8d-10
DocuColor 12/DCCS50
11-110 Paper Remains at Decurler Exit Sensor Long
Reissue
Finisher/Sorter
11-110 Paper Remains at Decurler Exit Sensor Long RAP
The Control Logic detected that paper remained on the Decurler Exit Sensor at power on.
Initial Actions
• Refer to BSD12.6 for the following procedure.
• Ensure that no paper is blocking t
he Decurler Exit sensor
• Ensure that P/J651 a
nd P/J654 on the Decurler Control PWB, and P/J658 on the
Decurler Exit Sensor are connected before beginning this RAP.
Procedure
Enter dC330 012-145 Decurler Exit Sensor. Press Start. The display is H.
YN
Go to F
lag 9, Fl
ag 10, and Flag 11 on BSD12.6 and check the harness for a short circuit.
If the harness is good, replace the Decurler Exit Sensor (PL 18.6). If the problem contin-
ues, replace the Decurler PWB (PL
18
.6).
+5VDC is measured between P/J654-2 and
GND on the Decurler PWB.
YN
Replace the Decurler Exit Sensor (PL 18.6).
Check the Decurler Exit Sensor for intermittent operat
io
n. If the sensor is good, Replace the
Decurler PWB (PL 18.6).
11-111 Paper Remains at Decurler Exit Sensor Short RAP
The Control Logic detected that paper remained on the Decurler Exit Sensor at power on.
Initial Actions
• Refer to BSD12.6 for the following procedure.
• Ensure that no paper is blocking the Decurler Exit sensor
• Ensure that P/J651 and P/J654 on
the Decurler Control PWB, and P/J658 on the
Decurler Exit Sensor are connected before beginning this RAP.
Procedure
Enter dC330 012-145 Decurler Exit Sensor. Press Start. The display is H.
YN
Go to F
lag 9, Fl
ag 10, and Flag 11 on BSD12.6 and check the harness for a short circuit.
If the harness is good, replace the Decurler Exit Sensor (PL 18.6). If the problem contin-
ues, replace the Decurler PWB (P
L 18.6
).
+5VDC is measured between P/J654
-2 and GND on the Decurler PWB.
YN
Replace the Decurler Exit Sensor (PL 18.
6).
Check
the Decurler Exit Sensor for intermittent operation. I
f the sensor is good, Replace the
Decurler PWB (PL 18.6).
