DocuColor 12/DCCS50
11-109 SCT Exit Sensor On Jam Short RAP
Finisher/Sorter
Reissue
YN
Enter dC330 012-070 Finisher Gate Solenoid Closed. Press Start
. The Finisher
Gate Solenoid energized.
YN
+24 VDC is measured between P
/J1042
-16 and P/J1042-14 on the Fin-
isher PWB.
YN
+24 VDC is Measured between P/
J1042-16 on
the Finisher PWB and
GND
YN
+24 VDC is measured between P/
J1042-14 on
the Finisher PWB
and GND.
YN
Go to the +24 VDC Wirenet and troubleshoot the wire between
P/
J1042-14 on t
he Finisher PWB and P/J45-6 on the Distribu-
tion PWB
Replace the Finisher PWB (PL 18.4)
Less than +1 VDC is measured between P/J1042-
16 on the Finisher
PWB and GND
YN
Replace the Finisher PWB (PL 18.4)
Go to Fl
ag 5 on BS
D12.7. Check the wires for an open circuit. If the wires
are good, replace the Finisher Gate Solenoid (PL 18.11).
Go to Flag 5 on B
SD12.7. Check the wires for an open circuit. If the wires are
good, ensure that the Finisher gate is connected to the Finisher Gate Solenoid
and that it moves freely. If the problem continues replace the Finisher Gate (PL
18.11) and the Finisher Gate Solenoid (PL 18.11).
Ensure that the Finisher Gate is connected to the Finisher Gate Solenoid and that it
mov
es f
reely. If the problem continues replace the Finisher Gate (PL 18.11) and the
Finisher Solenoid (PL 18.11).
• Check the paper path for any obstructions t
hat
could cause the paper to enter the
Vertical Transport.
• Ensure that the Mailbox Gate moves freely. I
f the problem continues replace the
Mailbox Gate (PL 18.11) and the Mailbox Gate Solenoid (PL 18.11).
• Ensure that the Finisher Gate moves freely. If the problem continues replace the Fin-
isher Gate (PL 18.
11
) and the Finisher Gate Solenoid (PL 18.11).
Enter dC330 012-107 SCT Entrance Sensor. Manually actuate the SCT Exit Sensor actuator.
The display changes from L to H to L as the actuator moves in and out of the sensor.
YN
The display is always H
YN
Go to Fl
ag 3 on BS
D12.10. Check the harness for a short circuit to ground. If the
harness is good, replace the SCT Exit Sensor (PL 18.13).
+5 VDC is measured between P/J1078
-1 and v-3
YN
+5 VDC is measured between P/
J1040-2 and
P/J1040-3.
YN
+5 VDC is measured between P/
J1026-3 and
P/J1026-2.
YN
+5 VDC is measured between P/
J880-3 and
P/J880-2.
YN
Go to the +5VDC F
igure 1 wirenet
and check wires for an open or
short circuit.
Go to Flag 17 on BS
D12.1 and check the harness for an open circuit.
Replace the Finisher PWB (PL 18.4).
Go
to Flag 2 on BS
D12.10 and check the harness for an open or a short circuit.
Replace or repair as required.
Go to Flag 3 on BSD12.10. Check the harness for an open circuit. If the harness is good,
replace t
he SCT Exit Sensor (PL 18.13).
With paper at the sensor, less than +1 VDC is measured between P/J10
40-1 and GND.
YN
Replace the SCT Exit Sensor (P
L 18.13
).
Check the following parts for wear, glazing, or slipping.
• Mailbox Entrance Roll (PL 18.10)
• Pinch Rollers (P
L 18.12
)
• SCT Exit Roll (PL 18.10)
• Drive Belt (PL 1
8.10)
Check the Drive Belt Tension Roll for proper tension.
A
F
F
G
