DocuColor 12/DCCS50
Machine Usage Modes, Self-test
Reissue
Principles of Operation
NVM Initialize
Password
Self-test
All machine subsystems which contain microcontrollers and microprocessors perform Power-
On Self-Test (POST) when DC power is first applied to them. If all POST procedures are
passed, the machine goes to normal operation. If a circuit fails a POST procedure, the machine
will attempt to notify the user. However, some failures may be due to a catastrophic hardware
failure which causes the machine to completely suspend operations.
The following are the PWBAs that are connected t
ogether or t
hat communicate the machine
status and operation.
The IOT CPU PWBA (Image Output Terminal) checks communications for the following:
UI PWBA
Post IPS PWBA
Mail Box Control PWBA
Serial Port for the PWS
Pre IPS PWBA (Image Process System):
Checks communications through the Post IPS PWBA and MEM. SYS PWBA
Controls the IOT through a direct connection with the IOT Drive PWBA
Checks DADF Control PWBA communications
UI PWBA (User Interface) Controls:
Control Panel Switches, LCD and the Touch Panel
Self-test for RAM and Control Panel
Post IPS PWBA implements image processing.
Post IPW PWBA and the MEM SYS PWBA are connected together and assist com-
munications between the Pre IPS PWBA and the IOT CPU PWBA.
MEM SYS PWBA stores the Image Data sent from the Pre IPS PWBA
IOT Drive PWBA controls the IOT by signals sent from the IOT CPU PWBA
DADF Control PWBA controls the DADF
and r
uns self-test of the RAM
Mailbox/Sorter Control PWBA controls the Mailbox/Sorter
Integrated Digital Front End (IDFE) Self-Test
Table 1 lists the POST routines performed by the IDFE.
Table 1 IDFE Power-On Self-Test
Test Performed What’s Tested Pass Indication Fail Indication
DC Power Test -
Power S
witch ON
DC Power to IDFE
Motherboard
Power LED stays on Power LED is off
BIOS Level Test IDFE Motherboard
components
F
ailure LED goes off at
end of test
Failure LED remains on
at end of test
Software Bootup
Sequence Tes
t
Application soft-
ware integrity
Heartbeat LED blinks
continuously
Software load attempts
fail; Heartbeat LED
remains on constantly
Printer Interface
DDI
Comms
Test 1
UART (internal
loopback)
Client level command to
IOT
Failure LED blinks pat-
tern 2, but software boot
contin
ues
