DocuColor 12/DCCS50
11-916 Bin 6 Full Stack RAP, 11-917 Bin 7 Full Stack
Reissue
Status Indicator RAPs
11-916 Bin 6 Full Stack RAP
The Control Logic detected that Bin 6 is full.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-916 Bi
n 6 Full
Stack RAP to troubleshoot this Fault Code.
Initial Actions
• Refer to BSD11.6 for the following procedure.
• Ensure that Bin 6 is empty
Procedure
Enter dC330 011-286 Bin 6 Full Sensor. Press Start. Manually move the actuator in and out
of the sensor The display Changes from H to L to H as the actuator is moved in and out
of th
e sensor.
YN
Replace the Mail Box Control PWB (PL 13.10).
Check the Bin 6 Full Sensor for intermittent operat
ion. I
f the problem continues, replace the
Mail Box Control PWB (PL 13.10).
11-917 Bin 7 Full Stack RAP
The Control Logic detected that Bin 7 is full.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-917 Bi
n 7 Full
Stack RAP to troubleshoot this Fault Code.
Initial Actions
• Refer to BSD11.6 for the following procedure.
• Ensure that Bin 7 is empty
Procedure
Enter dC330 011-287 Bin 7 Full Sensor. Press Start. Manually move the actuator in and out
of the sensor The display Changes from H to L to H as the actuator is moved in and out
of t
he sensor.
YN
Replace the Mail Box Control PWB (PL 13.
10).
Check t
he Bin 7 Full Sensor for intermittent operation. I
f the problem continues, replace the
Mail Box Control PWB (PL 13.10).
