Xerox DocuColor 12/DCCS50 User Manual

1/05
2-48
DocuColor 12/DCCS50
5-274 Original Size Sensor Fail RAP, 5-275 DADF
Reissue
Status Indicator RAPs
Replace the DADF Size Sensor 2 (Front) (PL 12.5).
Go to Flag 4 on BSD
5.3 and check the wire for an open circuit.
Replace the DADF Control PWB (PL 12.3).
Replace t
he DADF Control PWB (PL 12.3).
5-275 DADF RAM Check Fail RAP
The Control Logic has detected a DADF Size Sensor 1 or DADF Size Sensor 2 failure or a
DADF Ram Test failure after switching the power on or placing the originals in the Entrance
Tray.
Initial Actions
Check for the following:
• Ensure that the Document Handler is fr
ee of any paper or debris.
• Ensure that connectors P/J599, P/J
582 and P/J583 are seated correctly on the DADF
Control PWB and DADF Size Sensors 1 and 2, and there are no obvious crimped or bro-
ken wires.
• Refer to BSD 5.3 for the following procedure.
Procedure
Enter dC330 005-150 #1 Size Sensor. Press Start. Block DADF Size Sensor 1. The display
changed from H to L.
YN
With the sensor blocked, less than +1 VDC is measured at P
/J599-
8 on the DADF
Control PWB.
YN
With the sensor blocked, less than +1 VDC is measured at P/
J582-2 on
DADF
Size Sensor 1.
YN
There is +5 VDC between P
/J582-
1 and P/J582-3 on the DADF Size Sen-
sor 1.
YN
Go to Fl
ag 6 on BSD
5.3 and check the wires for an open circuit. If the
wires are good, replace the DADF Control PWB (PL 12.3).
Replace the DADF Size Sensor 1 (Rear) (PL 12.5).
Go
to Flag 3 on BS
D 5.3 and check the wire for an open circuit.
Replace the DADF Control PWB (PL 12.3).
Ent
er dC330 005-151 #2 Size Sensor. Pre
ss Start. Block DADF Size Sensor 2. The display
changed from H to L.
YN
With the sensor blocked, less than +1 VDC is measured at P/
J599-11 o
n the DADF
Control PWB.
YN
With the sensor blocked, less than +1 VDC is measured at P/
J583-2 on
the
DADF Size Sensor 2.
YN
There is +5 VDC between P
/J583-
1 and P/J583-3 on the DADF Size Sen-
sor 2.
YN
Go to Fl
ag 7 on BSD
5.3 and check the wires for an open circuit. If the
wires are good, replace the DADF Control PWB (PL 12.3).
A B C D
A B C D
