11-110 Paper Remains at Decurler Exit Sensor
Status Indicator RAPs
Reissue
11-110 Paper Remains at Decurler Exit Sensor Long RAP
The Control Logic detected that paper remained on the Decurler Exit Sensor at power on.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-
110 Paper
Remains at Decurler Exit Sensor Long RAP to troubleshoot this Fault Code.
NOTE: Ensure that Sorter S-1 Tag is installed.
Initial Actions
• Refer to BSD11.3 for the following procedure.
• Ensure that no paper is blocking t
he Decurler Exit sensor
• Ensure that P/J570 on t
he Mail Box Control PWB, Double Plug J571, P/J651 and P/
J654 on the Decurler Control PWB, and P/J658 on the Decurler Exit Sensor are con-
nected before beginning this RAP.
Procedure
Enter dC330 011-145 Decurler Exit Sensor. Press Start. The display is H.
YN
Go to Fl
ag 1 on BS
D 11.3 and check the harness for a short circuit. If the harness is good,
replace the Decurler Exit Sensor (PL 13.12). If the problem continues, replace the Mail
Box Control PWB (PL 13.10).
More than +4.3 VDC is measured between P/
J6
54-2 and GND on the Decurler Control
PWB.
YN
Replace the Decurler Exit Sensor (PL 13.12).
Check the Decurler Exit Sensor for intermittent operat
io
n. If the sensor is good, Replace the
Mail Box Control PWB (PL 13.10).
11-111 Paper Remains at Decurler Exit Sensor Short RAP
The Control Logic detected that paper remained on the Decurler Exit Sensor at power on.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-1
11 Paper
Remains at Decurler Exit Sensor Short RAP to troubleshoot this Fault Code.
NOTE: Ensure that Sorter S-1 Tag is installed.
Initial Actions
• Refer to BSD11.3 for the following procedure.
• Ensure that no paper is blocking the Decurler Exit sensor
• Ensure that P/J570 on t
he Mail Box Control PWB, Double Plug J571, P/J651 and P/
J654on the Decurler Control PWB, and P/J658 on the Decurler Exit Sensor are con-
nected before beginning this RAP.
Procedure
Enter dC330 011-145 Decurler Exit Sensor. Press Start. The display is H.
YN
Go to F
lag 1 on BSD 1
1.3 and check the harness for a short circuit. If the harness is good,
replace the Decurler Exit Sensor (PL 13.12). If the problem continues, replace the Mail
Box Control PWB (PL 13.10).
More than +4.3 VDC is measured between P/
J654-
2 and GND on the Decurler Control
PWB.
YN
Replace the Decurler Exit Sensor (PL 13.
12).
Check
the Decurler Exit Sensor for intermittent operation. I
f the sensor is good, Replace the
Mail Box Control PWB (PL 13.10).
