1/05
2-32
DocuColor 12/DCCS50
3-543 Rotation NG RAP, 3-550 Original Patch Not Ex-
Reissue
Status Indicator RAPs
3-543 Rotation NG RAP
The 3-543 Fault Code indicates that the rotation could not be done because the magnification
exceeded 100%.
Initial Actions
Refer to the User Guide in this procedure.
Procedure
PO/PO the machine. Fault Code 3-543 is still declared.
YN
Refer to the User Guide, Document Rotation, and help the customer to understand how to
avoid recurr
ence of t
he problem.
Replace the IOT CPU PWB (PL 9.
2).
3-550 Original Patch Not Exist RAP
The 3-550 Fault Code indicates that there was no position-detection patch on the original while
executing an automatic “KAICHO” revision.
Initial Actions
Refer to the User Guide in this procedure.
Procedure
PO/PO the machine. Fault Code 3-550 is still declared.
YN
Refer to the User Guide, Loading Documents, and help the customer to understand how
t
o avoid recur
rence of the problem.
Replace the IOT CPU PWB (PL 9.
2).
