11-142 V-Tra In Sensor On Jam Long RAP
Reissue
Status Indicator RAPs
11-142 V-Tra In Sensor On Jam Long RAP
The V-Tra In Sensor did not detect the lead edge of the paper within the specified time after the
Decurler Exit Sensor detected the lead edge of the same paper.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-
142 Mailbox
Entrance Sensor On Jam Long RAP to troubleshoot this Fault Code.
Initial Actions
Refer to BSD11.2 and BSD11.4 for the following procedure.
Check for the following:
• Obstructions in the Mail Box paper path
• Bent or out of position paper chutes/guides in the Mail Box paper path
• Ensure that the Mail Box front Door is closed properly
, in order t
o provide proper nip pres-
sure to the Vertical Transport Rolls.
• Ensure that connectors P/J562 on the Mail
Box Control PWB and P/J567 on the V-Tra In
Sensor are seated correctly and there are no obvious crimped or broken wires.
Procedure
The lead edge of the paper is at or past the V-Tra In Sensor
YN
The paper entered the Vertical Transport.
YN
The OCT Gate is in the down or Bin Tray position
YN
Enter d
C330 011-082 OCT Gate Solenoid Bin Tray On. Pre
ss Start. The
OCT Gate Solenoid energized.
YN
+24 VDC is measured between P/
J562-
2 and P/J562-3 on the Mail
Box Control PWB.
YN
+24 VDC is Measured between P/
J562-2 Mai
l Box Control PWB
and GND
YN
+24 VDC is measured between P/
J563-1 on
the Mail Box
Control PWB and GND.
YN
Go to the +24 VDC Wirenet and troubleshoot the wire
bet
ween P/
J563-1 on the Mail Box Control PWB and P/
J45-6 on the Distribution PWB
Replace the Mail Box Control PWB (PL 13.
10)
Le
ss than +1 VDC is measured between P/J562
-3 and GND
YN
Replace the Mail Box Control PWB (PL 13.
10)
Go t
o Flag 6 on BS
D 11.4. Check the wires for an open circuit. If the
wires are good, replace the OCT Gate Solenoid (PL 13.9).
Go to F
lag 6 on BSD 11.4. Check the wires for an open circuit. If the wires
are good,
ensure that the OCT gate is connected to the OCT Gate Sole-
noid and that it moves freely. If the problem continues replace the OCT
Ga
te
(PL 13.9) and the OCT Gate Solenoid (PL 13.9).
Ensure that the OCT gate is connected to the OCT Gate Solenoid and that it
moves f
reely. If the problem continues replace the OCT Gate (PL 13.9) and the
OCT Gate Solenoid (PL 13.9).
• Check the paper path for any obstructions t
hat could
cause the paper not to
enter the Vertical Transport.
• Ensure that the OCT gate moves freely. If the problem continues replace the
OCT Gate (P
L 13.9) and the OCT Gate Solenoid (PL 13.9).
Enter dC330 011-005 Mailbox Drive Motor. Press St
art. The Mail Box Transport Roll
is rotating.
YN
The Mail Box Drive Belt is moving.
YN
The Mail Box Drive Motor is rotating
YN
+24 VDC is measured between P/
J572-1
and P/J572-2 of the Mail
Box Drive Motor
YN
Go to F
lag 1 on B
SD11.2. Check the wires for an open circuit. If the
wires are good, replace the Mail Box Control PWB (PL 13.10).
Press Stop. +5 VDC i
s measured between P/J572-3 and GND.
YN
Go to F
lag 3 on BSD 11.2. Check the wire for an open circuit. If the
wire i
s good, replace the Mail Box Control PWB (PL 13.10).
Press Start. Less th
an +1 VDC is measured between P/J572-3 and
GND.
YN
Replace the Mail Box Control PWB (PL 13.
10)
Replace the Ma
il Box Drive Motor (PL 13.10).
Ens
ure that the Mail Box Drive Motor Pulley is fastened to the motor shaft.
• Check the Drive Belt Tension Roll for proper tension.
• Check the Drive Belt for Damage
• Check that the gear pulleys are properly
fas
tened to the drive rolls
Check the following parts for wear, glazing, or slipping.
• Entrance Roll (PL 13.9)
•
Pinch Rollers (PL 13.9
)
•Exit Roll (PL 13.9)
•
Drive Belt (PL 1
3.10)
