11-921 SCT Tray Full Stack RAP, 11-922 Sorter Stack-
Reissue
Finisher/Sorter
11-921 SCT Tray Full Stack RAP
The Control Logic detected that the SCT Tray is full.
Initial Actions
• Refer to BSD12.10 for the following procedure.
• Ensure that the SCT Tray is empty
• Ensure that connectors P/J1040 on t
he Finisher PWB, Shorting Plug P/J1080, and P/
J1079 on the SCT Full Sensor are seated correctly and there are no obvious crimped or
broken wires.
Procedure
Enter dC330 012-275 SCT Full Sensor. Press Start. The display is H.
YN
+5 VDC is measured between P
/J1
040-6 and DC-COM on the Finisher PWB.
YN
Go to F
lag 4 on BSD12.
10. Check the wire for a short circuit to ground. If the wire is
good, replace the SCT Full Sensor (PL 18.3).
Replace the Finisher PWB (PL 18.4).
Block the SCT Full Sensor with a sheet of paper. The display changes to L.
YN
+5VDC is measured between P/
J1079-1 and
P/J1079-3 on the SCT Full Sensor.
YN
+5 VDC is measured between P
/J
1040-7 and P/J1040-5 on the Finisher PWB.
YN
+5 VDC is measured between P
/J
880-3 and P/J880-2.
YN
Go to the +5VDC Fi
gu
re 1 wirenets and check wires for an open or short
circuit.
Check the wires between P/J44 on th
e Distribution PWB and P/J1026 on the
Finisher PWB. If the wires are OK, replace the Finisher PWB (PL 18.4).
Go to Flag 1 and Fla
g 4 on BSD12.10. Check the harness for an open or a short cir-
cuit. If the harness is good, replace the SCT Full Sensor (PL 18.3
).
Go to Flag 4 and check f
or an open or short circuit. If the problem continues, replace the
SCT Full Sensor (PL 18.3).
Check the SCT Full Sensor for intermittent operation, I
f the problem continues, replace the
SCT Full Sensor (PL 18.4).
11-922 Sorter Stacker Full RAP
The Control Logic has determined that bin 10 is full while operating in the Stack Mode.
Initial Actions
Ensure that there are no obstructions in the Stacker area
Procedure
Go to 11-921 SCT Tray Full Stack RAP to check out the SCT Full Sensor for any malfunctions.
