DocuColor 12/DCCS50
dC351 NVM Initialize, Save/Restore
General Procedures
Reissue
dC351 NVM Initialize, Save/Restore
Purpose
Save / Restore NVM
This option saves current NVM settings that were changed s
ince the last service call or to
restore the saved NVM settings since the last service call.
Machine Settings
This option saves the machine settings that were changed since the last service call or to
restore t
he machine settings since the last service call.
Dust Off Reset
Turns all counters back to zero.
NVM Background Read
This option will read/save all NVM locations found in dC131.
Procedure
1. Enter the Service Diagnostics Mode. Refer to Entering the Service Diagnostic Mode
using the PWS.
2. Select Adju
stments on the “Service Entry Screen.”
3. Select NVM
Init, S/R. The "NVM Initialize Screen (dC301)" is displayed.
4. Select the NVM Backgr
ound Processing (dC351) Tab.
5. Select Reset Al
l HFSI to reset all HFSI counters to zero.
6. Select Sta
rt Background Read to read the NVM settings to be saved/restored.
NOTE: Select Stop Background Read t
o stop a "Background Read" in progress.
NOTE: Table 1 list all NVM values read, saved or restored in NV
M Background Process-
ing dC351.
7. Once the Background Read has completed, select Sav
e Current NVM Settings or
Restore NVM Settings.
8. Once the NVM Settings have been "Saved" or "Restored", select Save Machi
ne Settings
or Restore Machine Settings.
Table 1
Code Description
702-002 Tools mode information
702-003 Tools mode information
702-004 Tools mode information
702-020 Tools mode information
702-022 Tools mode information
702-057 Document Size 1
702-122 Tools mode information
702-130 Tools mode information
702-168 Tools mode information
710-004 DADF Lead REGI Time Simplex
710-007 L-REGI Pulse Duplex 8.5x11
710-008 L-REGI Pulse Duplex A4 S
710-009 L-REGI Pulse Duplex 8.5x13
715-028 DADF IPS Offset- FS
715-029 REGI ADJ revise VAL-FS
715-091 White Ref Adjustment Coefficient - Red
715-092 White Ref Adjustment Coefficient - Green
715-093 White Ref Adjustment Coefficient - Blue
715-106 HOSEI SCAN
715-107 MB_SCAN
715-110 CCD Calibration Y Patch-R
715-111 CCD Calibration Y Patch-G
715-112 CCD Calibration Y Patch-B
715-113 CCD Calibration M Patch-R
715-114 CCD Calibration M Patch-G
715-115 CCD Calibration M Patch-B
715-116 CCD Calibration C Patch-R
715-117 CCD Calibration C Patch-G
715-118 CCD Calibration C Patch-B
715-119 CCD Calibration K Patch-R
715-120 CCD Calibration C Patch-G
715-121 CCD Calibration C Patch-B
715-125 Platen / DADF Selection
715-132 REGI Revise VAL- SS
715-133 MAG Revise VAL- SS
720-003 LS OFFSET Tray 1
720-004 LS OFFSET Tray 2
720-005 LS OFFSET Tray 3
720-006 LS OFFSET Tray 4
720-007 LS OFFSET Tray 5
720-008 LS OFFSET Duplex
720-018 ERASE LE
720-019 ERASE TE
720-020 ERASE SIDE
730-001 TIS Parameter
730-002 MUC Adj
730-003 MUC Adj for OHP
730-004 MUL M Rate for Y-Y
730-005 MUL M Rate for M-Y
730-006 MUL M Rate for C-Y
730-007 MUL M Rate for Y-M
Table 1
Co
de
Description
