DocuColor 12/DCCS50
07-280 HCF Communication Fault RAP , 07-289
High Capacity Feeder
Reissue
07-280 HCF Communication Fault RAP
Fault Code 07-280 indicate that an HCF communication fault has occurred.
Procedure
Go to Flag 1 on BSD 8.13. Check the wires for an open circuit or a short circuit to ground. If the
wires are good, replace the HCF Control PWB (PL 15.16). If the problem continues, replace
the IOT CPU PWB (PL 9.2).
07-289 HCF Broken Failure RAP
The HCF Stack Height Sensor failed to change state within the specified time after the HCF
Tray started to lift.
NOTE: Prior to switching off the machine, ensure all pendi
ng jobs are saved.
Initial Actions
• Check for obstructions in the paper path.
• Ensure connector P/J8
41 on the HCF Control PWB is seated properly.
• Refer to BSD 7.11 and 7.12 in the following procedure.
Procedure
Enter dC330, 007-186 HCF Stack Height Sensor and press Start. Pull the HCF Tray out.
The display changed from L to H.
YN
Check for +5VDC between pins 1 and 3 of P
/J
841 on the HCF Control PWB. +5VDC is
measured between pins 1 and 3 of P/J841.
YN
Check for +5VDC between pins 3 and 4 of J2
HCF Cont
rol PWB. +5VDC is mea-
sured between pins 3 and 4 of J2.
YN
Check for +5VDC between pins 20 and 9 of P/J44 Distribution PWB. +5VDC is
measu
red b
etween pins 20 and 9 ofP/J44.
YN
Go to Wirenet +5 VDC-1 Figure 7.
Go to F
lag 3 on BS
D 8.13. Check the connector and wiring for an open circuit.
Replace the HCF Control PWB (PL 15.16
).
Go to Flag 2 and F
lag 4 on BSD 7.11. Check the connectors and wiring for an open cir-
cuit. If the connectors and wiring are OK, then replace the S
tack Height Sensor (PL
15.12).
Enter dC330, 007-079 HCF Elevator Motor and press
Start.
CAUTION
Do not operate the component control more than twice before resetting paper position. To
lower the paper f
rom the feed position, pull out respective tray. If the tray is overdriven it will be
hard to pull out and may cause component damage.
Ensure that the Elevator Motor energizes. The Elevator Motor energizes and then deener-
gizes within 30 seconds.
YN
Check for +24VDC between pins 2 and 1 of P
/J
845 HCF Control PWB. +24VDC is mea-
sured between pins 1 and 2 of P/J845 on
the HCF Control PWB (This measurement
must be taken within 30 seconds after closing the tray.)
YN
Check for +24VDC between pins 1 and 2 of J2HCF
Control PW
B. +24VDC is mea-
sured between pins 1 and 2 of J2 on the
HCF Control PWB.
A B
