DocuColor 12/DCCS50
5-501 DADF Document Size Irregular RAP, 5-503
Status Indicator RAPs
Reissue
Go to Flag 4 on BSD 5.3 and check the wire for an open circuit.
Replace the DADF Control PWB (PL 12.3).
Replace t
he following until the problem is resolved
• DADF Control PWB (PL 1
2.3).
• DADF Size Sensor 1 (Rear) (PL 1
2.5)
• DADF Size Sensor 2 (Front) (PL 12.5).
5-503 Miss Doc Reset RAP
The Missing Document Reset fault code (05-503) is displayed when the Control Logic has
detected that after counting and returning the originals, there is a mismatch between the num-
ber of pages counted and the actual number of pages.
Procedure
• Ensure that the Document Handler is free of any paper or debris.
• Remove and reinsert the originals in the DADF Entrance Tray.
• Run the job again.
