Xerox DocuColor 12/DCCS50 User Manual

1/05
1-6
DocuColor 12/DCCS50
Detailed Maintenance Activities
Reissue
Service Call Procedures
Detailed Maintenance Activities (HFSI)
Procedure
1. Clean the ADC Sensor (PL 7.5) on every call.
2. Check Developer Housings for loose bearings or wo
rn shaft at every service call
3. Enter Diagnostics and select dC 135.
4. Perform the Service Action in Table 1 f
or High Frequency Service Item (HFSI) counters
that are over threshold or approaching the threshold. Using the customer's output volume
numbers (high, medium, or low volume), evaluate which HFSI actions should be accom-
plished now to avoid an additional service call in the near future.
5. Refer to C
leaning Pr
ocedures for detailed cleaning instructions.
Table 1 HFSIs
Chain-
Link
Comp
onent Increment Criteria Threshold Service Action Required
006-801 Counter only Feed Count -1 No service required - counter only
006-802 Counter only Scan Count -1 No service required - counter only
007-800 HCF Feed Counter Total feeds from HCF 100K Replace the HCF Feeder Nudger Assembly (PL 15.14
) and Retard Assembly (PL 15.15). Reset
the counter.
008-801 Tray 1 Feed Roll Total feeds from Tray 1 300K Replace the Feed/Nudger Roll Assembly (PL 2.5) and Ret
ard Assembly (PL 2.6). Reset the
counter.
008-802 Tray 2 Feed Roll Total feeds from Tray 2 300K Replace the Feed/Nudger Roll Assembly (PL 2.5) and Ret
ard Assembly (PL 2.6). Reset the
counter.
008-803 Tray 3 Feed Roll Total feeds from Tray 3 300K Replace the Feed/Nudger Roll Assembly (PL 2.5) and Ret
ard Assembly (PL 2.6). Reset the
counter.
008-804 Tray 4 Feed Roll Total feeds from Tray 4 300K Replace the Feed/Nudger Roll Assembly (PL 2.5) and Ret
ard Assembly (PL 2.6). Reset the
counter.
008-810 Tray 5 Feed Roll Total feeds from Tray 5 80K Replace the Feed/Nudger Roll Assembly (PL 2.11) and Ret
ard Assembly (PL 2.12). Reset the
counter.
008-825 Duplex Aligner Roll Total feeds from Duplex 9999K Run-to-failure
009-805 IBT Belt: CV, PV Total A4/LTR LEF copies (larger paper = 2 counts) 120K Replace the IBT Belt (PL 7.
5). Reset this counter and counter 009-806.
009-806 IBT Belt: Cycle Total IBT Belt revolutions 660K Replace the IBT Belt (PL 7.
5). Reset this counter and counter 009-805.
009-807 1st BTR Total A4/LTR LEF copies (larger paper = 2 counts) 9999K Run-to-failure
009-808 Back Up Roll Total A4/LTR LEF copies (larger paper = 2 counts) 9999K Run-to-failure
009-809 2nd BTR Unit Total A4/LTR LEF copies (larger paper = 2 counts) 400K Replace the 2nd BTR (PL 7.
9). Reset the counter.
NOTE: Perform GP 20 2nd BTR Service Procedure at 100K
intervals
009-812 CC Assy Discharge time (0.1 hr./count) 9999K This location does not automatically reset when CRU is
replaced -DISREGARD
009-819 Transfer Trim Total A4/LTR LEF copies (larger paper = 2 counts) 120K Clean inside of Transfer Module and reset the counter.
009-823 Bracket Assembly - Oil 9999K No longer used - DISREGARD
009-835 Belt Cleaner Blade Total A4/LTR LEF copies (larger paper = 2 counts) 9999K Run-to-failure
009-838 Drive Roll Cleaner Total A4/LTR LEF copies (larger paper = 2 counts) 9999K Run-to-failure
009-841 Ozone Filters Each color pass (4C = 4, B/W = 1) 320K Replace both Ozone Filters (PL 10.
2) and reset
the counter.
009-843 Suction Filter Each color pass (4C = 4, B/W = 1) 320K Replace the Suction Filter (PL 10.2
) and reset the counter.
009-846 CC Dust Filter Each color pass (4C = 4, B/W = 1) 9999K This location does not automatically reset when CRU is
replaced -DISREGARD
009-850 Developer Housing - K Developer Motor ON time (0.1 hr./count) 1000 Replace Developer Housing (PL 6.6).
009-851 Developer Housing - Y Developer Motor ON time (0.1 hr./count)
1000 Replace Developer Housing (PL 6.6).
009-852 Developer Housing - M Developer Motor ON time (0.1 hr./count) 1000 Replace Developer Housing (PL 6.6).
009-853 Developer Housing - C Developer Motor ON time (0.1 hr./count) 1000 Replace Developer Housing (PL 6.6).
009-880 Trickle Bottle Dispense Motor ON time (0.01 hr./count) 200 This location does not automatically reset when CRU is
replaced -DISREGARD
