1/05
6-81
DocuColor 12/DCCS50
dC131SYS NVM List (752)
General Procedures
Reissue
dC131SYS NVM List (752)
Table 1 SYS NVM List (752)
Chain-
Link Nam
e Default Range Description
752-001 MARKET - 0-3 0=FX
1=AP
2=NASG
3=ESG
Machine determines the market
fr
om
this parameter. This area is
not initialized.
752-002 EPSV EXIST - 0-1 0= No
1= Yes
752-003 TELEPHONE LINE
EX
IST
- 0-1 0= No
1= Y
es This is sent as optional
data when
entering into the PWS
Service Mode.
752-004 MDSS EXIST 0 0-1 0 = No MDSS
1 = MDSS Connected
752-005 XJ CODE PIN Number 1 - 0-255 Factory management code
752-006 XJ CODE PIN Number 2 - 0-255 Factory management code
752-007 XJ CODE PIN Number 3 - 0-255 Factory management code
752-008 Machine CONFIG - 0-4 0=DC
1=CP
2=CPS
3=P
4=P (with UI)
For the optional data sent when
ent
ering i
nto the PWS Service
Mode
752-009 DADF EXIST - 0-1 0= None (Platen)
1= DADF
For the optional data sent when
ent
ering i
nto the PWS Service
Mode (Automatically set at Power
On)
752-010 OUTPUT CONFIG - 0-3 0= No (Top tray),
1= Offset Catch Tray,
2= Sorter,
3= Mail Box
For the option data sent when
ent
ering i
nto the PWS Service
Mode (Automatically set at Power
On)
752-011 MULTI TRAY CONFIG - 0-1 0= No,
1= HCF
For the optional data sent when
ent
ering in
to the PWS Service
Mode (Automatically set at Power
On)
752-012 (Spare) - 0-1 -
752-013 PRODUCT CODE No 1 - 0-255 Product code (ASCII Code)
752-014 PRODUCT CODE No 2 - 0-255 Product code (ASCII Code)
752-015 PRODUCT CODE No 3 - 0-255 Product code (ASCII Code)
752-016 PRODUCT CODE No 4 - 0-255 Product code (ASCII Code)
752-017 EPC Option Config 0 0-2 0 = no EPC
1 = EPC @ 1st DDI
2 = EPC @ 2nd DDI
752-018 Auto Upgrade NVM - 0-65535 NVM automatic upgrade function
af
te
r introduction in the market.
Table 1 SYS NVM List (752)
Chain-
L
ink Name Default Range Description
