Xerox DocuColor 12/DCCS50 User Manual

1/05
8d-27
DocuColor 12/DCCS50
11-911 Bin 1 Full Stack RAP, 11-912 Bin 2 Full Stack
Finisher/Sorter
Reissue
11-911 Bin 1 Full Stack RAP
The Control Logic detected that Bin 1 is full.
Initial Actions
• Refer to BSD12.9 for the following procedure.
• Ensure that Bin 1 is empty
Procedure
Enter dC330 012-281 Bin 1 Full Sensor. Press Start. Manually move the actuator in and out of
the sensor The display Changes from H to L to H as the actuator is moved in and out of
the s
ensor.
YN
Press Stop. +5VDC is measured between P
/J1002-
1 and DC COM on the Mailbox
PWB.
YN
+5VDC is measured between P/
J1031-11 an
d DC COM on the Finisher PWB.
YN
Replace the Finisher PWB (PL 18.4).
Go to Fl
ag 1 on
BSD12.9 and check the wires for an open circuit.
Replace the Mailbox PWB (PL 1
8.11).
Check the Bin 1 Full Sensor for intermittent operation. I
f the problem continues, replace the
Mailbox PWB (PL 18.11).
11-912 Bin 2 Full Stack RAP
The Control Logic detected that Bin 2 is full.
Initial Actions
• Refer to BSD12.9 for the following procedure.
• Ensure that Bin 2 is empty
Procedure
Enter dC330 012-282 Bin 2 Full Sensor. Press Start. Manually move the actuator in and out of
the sensor The display Changes from H to L to H as the actuator is moved in and out of
the senso
r.
YN
Press Stop. +5VDC is measured between P
/J10
02-2 and DC COM on the Mailbox
PWB.
YN
+5VDC is measured between P
/J1031
-10 and DC COM on the Finisher PWB.
YN
Replace the Finisher PWB (PL 18.
4).
Go
to Flag 2 on BS
D12.9 and check the wires for an open circuit.
Replace the Mailbox PWB (PL 18.11
).
Check the Bin 2 Full Sensor for intermittent operation. I
f the problem continues, replace the
Mailbox PWB (PL 18.11).
