Xerox DocuColor 12/DCCS50 User Manual

1/05
8d-23
DocuColor 12/DCCS50
11-193 Decurler Exit Sensor Static Jam RAP, 11-
Finisher/Sorter
Reissue
11-193 Decurler Exit Sensor Static Jam RAP
The Control Logic detected paper remained on the Decurler Exit Sensor.
Initial Actions
• Refer to BSD12.6 for the following procedure.
• Ensure that no paper is blocking t
he Decurler Exit sensor
• Ensure that P/J651 a
nd P/J654 on the Decurler Control PWB, and P/J658 on the
Decurler Exit Sensor are connected before beginning this RAP.
Procedure
Enter dC330 012-145 Decurler Exit Sensor. Press Start. The display is H.
YN
Go to F
lag 9, Fl
ag 10, and Flag 11 on BSD12.6 and check the harness for a short circuit.
If the harness is good, replace the Decurler Exit Sensor (PL 18.6). If the problem contin-
ues, replace the Decurler PWB (PL
18
.6).
+5VDC is measured between P/J654-2 and
GND on the Decurler PWB.
YN
Replace the Decurler Exit Sensor (PL 18.6).
Check the Decurler Exit Sensor for intermittent operat
io
n. If the sensor is good, Replace the
Decurler PWB (PL 18.6).
11-301 Mailbox Door Interlock Open RAP
Mailbox Door Interlock Open Failure. This status code is declared when the Mailbox Door Inter-
lock Switch is open.
Initial Actions
• Refer to BSD12.1 for the following procedure.
• Ensure that P/J
1033 on the Finisher PWB, and P/J1018 on the Mailbox Door Interlock
Switch are connected before beginning this RAP.
• Check the Front Door for proper alignment.
• Verify that the Front Door closes properly.
Procedure
Enter dC330 012-301 Mailbox Door Intlk Sw. The state of the Mailbox Door Interlock
Switch is Low and switches to High when the Mailbox Door is opened.
YN
With the Front Cover closed, there is +0 VDC between P
/J1
033-1 on the Finisher
and GND.
YN
Go to the F
lag 1
and Flag 2 on BSD12.1. Check the wires for an open circuit. If the
wires are good, replace the Mailbox Door Interlock Switch (PL 18.11). If the problem
continues, replace the Finisher PWB (PL 18.4).
Check the Mailbox Door Interlock Switch for intermittent operation. Ensure that the switch
and t
he cove
r are properly aligned and adjusted. If the problem continues, replace the
Finisher PWB (PL 18.4).
Check the Mailbox Door Interlock Switch for intermittent operation. Ensure that the switch and
the
cover are properly aligned and adjusted. If the problem continues, replace the Finisher
PWB (PL 18.4).
