DocuColor 12/DCCS50
11-512 Offset Catch Tray / Simple Catch Tray Full
Status Indicator RAPs
Reissue
11-512 Offset Catch Tray / Simple Catch Tray Full Stack
RAP
The Control Logic detected that the Offset Catch Tray/Simple Catch Tray is full.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-51
2 Simple Catch
Tray (SCT) Full Stack RAP to troubleshoot this Fault Code.
Initial Actions
• Refer to BSD11.7 for the following procedure.
• Ensure that the Offset Catch Tray/Simple Catch Tray is empty
• Ensure that connectors P/J564 on t
he Mail Box Control PWB, Shorting Plug P/J801A,
Double Plug J880, and P/J807 on the Full Stack Sensor are seated correctly and there
are no obvious crimped or broken wires.
Procedure
Enter 011-275 Full Stack Sensor. Press Start. The display is H.
YN
+5 VDC is measured between P/
J5
64-5 and DC-COM on the Mail Box PWB.
YN
Go to Fl
ag 1 on BS
D11.7. Check the wire for a short circuit to ground. If the wire is
good, replace the Full Stack Sensor (PL 14.1).
Replace the Mail Box Control PWB (PL 13.10).
Block the Full Stack Sensor with a sheet of paper. The display changes to L.
YN
+5 VDC is measured between P/
J5
64-4 and P/J564-3 on the Mail Box PWB.
YN
CR1 on the Mail Box Control PWB is on.
YN
Go to the +5 VDC wirenet and troubleshoot the wires between P/
J569-1 and
P/
J44-6 on the Distribution PWB.
Replace the Mail Box Control PWB (PL 13.10).
Go to Flag 1 and F
lag 2 on BSD 11.7. Check the harness for an open circuit. If the har-
ness is good, replace the Full Stack Sensor (PL 14.1).
Check the Full Stack Sensor for intermittent operation, I
f the problem continues, replace the
Full Stack Sensor (PL 14.1).
11-911 Bin 1 Full Stack RAP
The Control Logic detected that Bin 1 is full.
NOTE: If this machine has a Finisher/Sorter Accessory, go to Section 8D, 11-91
1 Bin 1 Full
Stack RAP to troubleshoot this Fault Code.
Initial Actions
• Refer to BSD11.6 for the following procedure.
• Ensure that Bin 1 is empty
Procedure
Enter dC330 011-281 Bin 1 Full Sensor. Press Start. Manually move the actuator in and out
of the sensor The display Changes from H to L to H as the actuator is moved in and out
of t
he sensor.
YN
Replace the Mail Box Control PWB (PL 13.
10).
Check t
he Bin 1 Full Sensor for intermittent operation. I
f the problem continues, replace the
Mail Box Control PWB (PL 13.10).
