Xerox DocuColor 12/DCCS50 User Manual

1/05
10-92
DocuColor 12/DCCS50
Paper Tray Specifications
Reissue
Principles of Operation
Paper Tray Specifications
The Paper Trays are numbered 1-4, with Tray 1 at the top. Tray 1 is different in size and paper
holding capacity from the other trays. Trays 2, 3 and 4 are identical and can be interchanged
within the machine. The trays slide in and out on a side rail assembly from of the front of the
machine. When the trays are inserted all the way into the machine, a switch is activated to indi-
cate on the User Interface that a tray is present.
Each tray has Paper Guides that can be adjust
ed by the
user to accommodate different paper
sizes. The Paper Guides in each tray automatically indicate to the machine the paper size in
that tray. This information is provided on the User Interface for the operator.
Tray 5 is located on the side of the machine. This is used for feeding 1 to 100 sheets of paper
(28lb-30lb),
heavier weight
papers and transparency material. It also holds the optional enve-
lope feeder.
Refer to T
able 1 for the tray specifications. Fig
ure 1 shows the electrical interface for Tray 1,
and Figure 2 shows the electrical interface for Tray 2. The electrical interfaces for Trays 3 and
4 are the same as Tray 2.
Table 1 Paper Tray Specifications
Trays Capacity Paper Sizes Paper Weights Notes
Tray 1 500 sheets 8.5x11.0
8x10
A4
B5
No envelopes
,
t
ransparencies, or
heavy weight
paper
Trays 2, 3, 4 550 sheets 11x17
8.5x14
8.5x13
8.5x11
8x10
B4
A3
B5
A4
No envelopes
,
t
ransparencies, or
heavy weight
paper
Tray 5 100 sheets
(20 lb, or less
s
heets
for
heavier weights)
Any less than 250
gs
m,
less than 140 lb
index
;
less
than90 lb
c
over
O
ptional envelope
feeder; us
able for
transparencies,
h
eavy weight and
h
ole punched/
drilled papers
