8-110 Tray 2 Feed Out Sensor On Jam RAP, 8-112
Status Indicator RAPs
Reissue
YN
There is +5 VDC between P/J801B-
8 on the Tray PWB and GND.
YN
Go to Fl
ag 6 on BS
D 8.2 and check the harness for an open circuit. If the har-
ness is good, replace the IOT Drive PWB (PL 9.
2).
Replace the Tray PWB (PL 9.3).
Replace the Tray 2 Takeaway Feed Clutch (PL 2.7
A).
Enter dC330 008-025 Take Away Motor. Pr
ess Start. The Takeaway Motor energizes.
YN
Go to the T
akeaway Motor RAP
Check/
replace the following components until the problem is resolved. Replace any compo-
nents that are worn, broken, binding, or slipping.
• Pinch Rolls and Springs in the Left Cover (PL 2.
8)
• Tray 2 Feeder Assembly (PL 2.4)
8-112 Tray 2 Feed Out Sensor On RAP
The Tray 2 Feed Out Sensor detected paper when closing the Front Cover or when power was
switched on.
Initial Actions
• Refer to BSD 8.2 and BSD 8.10 for the following procedure.
• Check for any obstructions in the paper path.
• Check the actuator for the Tray 2 Feed Out Sensor.
Procedure
Enter dC330 008-110 Tray 2 feed out Sensor. Press Start. The display indicates L.
YN
Go to F
lag 3 and Fl
ag 4 on BSD 8.2 and check the harness for an open circuit. If the har-
ness is good, replace the Tray 2 Feed O
ut Sensor (PL 2.8).
If the fault code is present and can not be cleared,
replace the Tray PWB (PL 9.3). If the fault
code is not present and is occurring intermittently, go to Flag 3 on BSD 8.2 and check the har-
ness for an intermittent short circuit. If the harness is O
K,
replace the Tray 2 Feed Out Sensor
(PL 2.8). If the problem continues, replace the Tray PWB (PL 9.3).
